Fuel Lines for 1984 Mercedes-Benz 500 SEC
No.
Part # / Description / Price
Price
5
MSRP $115.00
$86.25
5
23
Fuel Hose
Mercedes-Benz
Mercedes-Benz Notes: AUSTRALIA UP TO END OF MODELYEAR 94
Description: From pressure regulator to fuel cooler.
29
Cooler Mercedes-Benz
Mercedes-Benz Notes: AUSTRALIA UP TO END OF MODELYEAR 94
Description: (fuel cooler). Fuel cooling.
MSRP $680.00
$510.00
MSRP $680.00
$510.00
32
Round-Sect Sealing Ring Mercedes-Benz
Mercedes-Benz Notes: AUSTRALIA UP TO END OF MODELYEAR 94
Description: Pipeline. 17x2 mm.
MSRP $4.30
$3.23
MSRP $4.30
$3.23
35
Fuel Hose Mercedes-Benz
Mercedes-Benz Notes: AUSTRALIA UP TO END OF MODELYEAR 94
Description: From fuel cooler to return line.
68
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Breather line to breather valve. Return.
71
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Between combination valve and breather pipe. Regeneration valve. Return hose to return line. From fuel tank to breather valve.
MSRP $4.00
$3.00
MSRP $4.00
$3.00
83
86
Tensioner Mercedes-Benz
Mercedes-Benz Description: Underbody left. Fuel line to floor,right. To mount fuel lines. In wheelhouse front left. To firewall and longitudinal member. Brake line to cross member.
MSRP $5.00
$3.75
MSRP $5.00
$3.75
104
Holder Mercedes-Benz
Mercedes-Benz Description: Activated charcoal filter. Windshield washer pipe line to right side member. Aeration/ventilation. Regeneration line. Line to cross member. Fuel line to partition panel. On damper strut dome bracket,right. Pipe line to right wheel arch.
MSRP $6.50
$4.88
MSRP $6.50
$4.88
119
Clamp Mercedes-Benz
Mercedes-Benz Description: Fuel lines on floor under rear seat. Feed line to air water canal. Fuel lines to vehicle floor 17 x 20 mm. Fuel lines to body. Return line to body. Cable harness mounting. High pressure hose to cross member.
MSRP $2.90
$2.18
MSRP $2.90
$2.18
131
Damping Strip Mercedes-Benz
Mercedes-Benz Description: Fastening fuel lines to longitudinal member. Fuel lines to vehicle floor. Extinguishing agent line. Fuel lines on floor under rear seat. Feed line. Fuel line mounting. Gas line. Return line to body. Cable harness mounting. High pressure hose to cross member.
143
Rubber Guide Mercedes-Benz
Mercedes-Benz Description: Fuel lines to body. Lines to rear floor above rear axle, center. Fuel lines to cowl. Lines to frame. Fuel lines to front partition panel. Fuel lines under rear seat. Mounting pipe line.
MSRP $7.25
$5.44
MSRP $7.25
$5.44
152
Tapping Screw Mercedes-Benz
Mercedes-Benz Description: Bz6,3x13. Bracket mounting. Control unit to the right of legroom.
153
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M6. Bracket to water tank. Mounting parts. Control unit. Bracket mounting. Brake booster assembly to asr bracket. Fuel lines to cowl. Transistorized ignition switchgear to wheelhouse panel. Roller blind to rear panel covering, top.
MSRP $3.40
$2.55
MSRP $3.40
$2.55
